8x8 IS-88
Datalogic
Salidas 3 hilos a transistor PNP NO
Salida a cable o a conector M8.
Rectangular.
Metálico.
| NOMINAL SWITCHING DISTANCE (Sn) | FLUSH: 1,5 mm |
| NOMINAL VOLTAGE | 10 ÷ 30 VDC (-15 / +10%) |
| RESIDUAL RIPPLE | ≤ 10% |
| HYSTERESIS | < 10% |
| MAX. OUTPUT CURRENT | 200 mA |
| RESIDUAL CURRENT | < 10 mA |
| VOLTAGE DROP (Sensor ON) | < 1.2 V |
| OPERATION LED | Present |
| SWITCHING FREQUENCY | 500Hz |
| START UP DELAY | <75ms |
| REPEATABILITY | ≤ 3% |
| SHORT CIRCUIT PROTECTION | Present (self-resetting) |
| ELECTRIC PROTECTIONS | Against polarity reversal - inductive loads |
| TEMPERATURE LIMITS | - 25 ÷ +70 °C |
| PROTECTION DEGREE | IP 67 |
| HOUSING MATERIAL | Nickel Plated Brass |
| WEIGHT - Cable output | 80 g |
